Want to upgrade your C8 Corvette with authentic vertical lambo doors? Whether you're a DIY enthusiast or prefer our mobile install service or certified shop installation, this guide walks you through the essential steps based on the official Vertical Doors Inc. (VDI) instructions.
✅ Mobile Install Available Nationwide Call 702.900.6105
✅ Shop Install Options Also Offered
✅ Fits 2020–2025 C8 Corvette Models
🔧 Tools & Parts You'll Need
Included in Your VDI Kit:
-
Right & left hinge assemblies
-
2 shocks
-
Shoulder bolts, pins, and hardware
Recommended Tools:
-
Ratchets, sockets (7mm–13mm), Allen wrenches
-
Phillips & flathead screwdrivers
-
Fork tool, T15 Torx bit
-
Air grinder, cutter, and painter’s tape
-
Locktite Red, grease
-
Spacers and zip ties
🪛 Step-by-Step C8 Corvette Lambo Door Installation
Step 1: Disconnect the Battery
Safety first — always disconnect the battery before beginning.
Step 2: Remove the Front Bumper & Fenders
-
Remove front plastic trim and side fender trim.
-
Unbolt 6 top bumper bolts and clips, including underbody fasteners.
-
Turn the wheels for access and unscrew the bumper from the wheel well.
-
Carefully unplug bumper wiring harnesses (3 total).
Step 3: Remove the Fender
-
Unbolt 3 top screws and 2 inner bolts per side.
-
Remove fender liners and hidden bolts behind wheel well.
-
Remove 1 bolt with door open, then remove the fender entirely.
Step 4: Remove the Door Catch & Interior Panel
-
Unbolt the door catch from the apron.
-
Remove door panel, speaker, and any storage compartments.
-
Disconnect electrical connectors.
Step 5: Extend Wiring Harness
-
Carefully unwrap and extend 3 wires on driver side and 2 on passenger side (includes SRS sensor and door lock).
-
Use cloth tape for flexibility.
-
Modify rubber boot and secure with zip ties for a watertight fit.
Step 6: Prepare for Hinge Installation
-
Use painter’s tape to mark original door placement.
-
Secure door with shims or paint sticks to hold it in place.
-
Remove the factory hinges.
Step 7: Install the VDI Hinges
-
Align and bolt in the VDI hinge (long bolts to the body, short to the door).
-
Adjust Allen set screw to align door with striker.
-
Do not fully tighten until the shock is installed.
Step 8: Install the Shock & Shoulder Bolt
-
Grease and Loctite the shoulder bolt as required.
-
Install the shock, secure it with the pin.
-
Fine-tune the set screw for door alignment.
💡 Pro Tip: Open, close, and lift the door several times to ensure smooth operation before final reassembly.
Step 9: Modify Fender for Clearance
-
Slightly trim the inner edge of the fender with a grinder.
-
Smooth the edge and use touch-up paint for a clean finish.
Step 10: Reassemble
-
Reinstall the speaker, door panel, and door catch.
-
Replace the fender and front bumper (ensure wires aren't pinched).
-
Reconnect the battery and test door movement thoroughly.
📏 Final Fitment Tip
Some C8 models may require light sanding on the door edge to maintain factory gaps. Always check door clearance before installing the fender permanently.
